Monolithic Refractories

INCT Series

INCT is a castable with excellent insulating properties, which can be directly used on the surface and operating surface of various equipment to prevent heat dissipation and provide stable refractory and insulation properties at high temperatures. Its selection should be considered based on the temperature inside the furnace, insulation properties, and construction methods. Casting, troweling, and spraying are possible construction methods.
Item＼Product INCT-160S INCT-160 INCT-140S INCT-140 INCT-120S INCT-120
Maximum Service Temperature(℃) 1600 1600 1400 1300 1200 1200
Dry Material Required for Estimating(t/㎥) 1.5 1.45 1.20 1.35 0.95 1.10
Permanent Linear Change(%) 110℃×24h -0.06 -0.06 -0.06 -0.06 -0.06 -0.06
1000℃×3h -0.12 -0.12 -0.24 -0.15 -0.35 -0.30
1500℃×3h -0.15 -0.18 -0.24 -0.20 -0.55 -0.40
Cold Crushing Strength(N/㎟) 110℃×24h 9.80~12.7 8.82~10.8 4.90~6.86 8.82~10.8 3.92~5.88 4.90~6.86
1000℃×3h 5.88~7.84 4.90~6.86 2.94~5.88 3.92~5.88 1.96~3.92 1.96~3.92
1200℃×3h 11.7~14.7 8.82~11.7 4.90~6.86 5.88~7.84 - -
Modulus of rupture strength(N/㎟) 110℃×24h 2.94~4.90 1.96~3.92 0.98~2.94 2.94~4.90 0.49~1.96 0.49~1.96
1000℃×3h 0.49~2.94 0.98~2.94 0.49~1.96 0.98~2.45 0.98~1.96 0.98~1.96
1200℃×3h 2.94~4.90 2.94~4.90 0.98~2.94 0.98~2.94 - -
Thermal Conductivity(Kcal/m) 250℃ 0.64 0.45 0.29 0.33 0.25 0.30
550℃ 0.74 0.48 0.31 0.36 0.28 0.34
800℃ 0.78 0.52 0.34 0.43 0.31 0.37
Chemical Composition(%) Al₂O₃ 90 65 42 45 30 33
SiO₂ - 27 37 35 50 47
Water Required(%) 20 23 35 28 52 43
Setting Type Hydraulic
Installation Method Casting, Gunning
Packaging 25kg
Item＼Product INCT-110S INCT-110 INCT-100S INCT-100 INCT-90 INCT-80
Maximum Service Temperature(℃) 1100 1100 1000 1000 900 800
Dry Material Required for Estimating(t/㎥) 0.90 1.05 0.80 1.00 0.90 0.85
Permanent Linear Change(%) 110℃×24h -0.06 -0.06 -0.06 -0.06 -0.06 -0.06
1000℃×3h - - -0.70 -0.50 -0.80 -0.8
1500℃×3h -0.72 -0.60 - - - -
Cold Crushing Strength(N/㎟) 110℃×24h 2.94~4.90 1.96~4.90 1.96~4.90 2.94~4.90 0.49~1.96 0.49~1.96
800℃×3h - - 0.49~1.96 0.98~2.94 - -
1000℃×3h 0.98~1.96 0.98~2.94 - - - -
Modulus of rupture strength(N/㎟) 110℃×24h 0.49~1.96 0.49~1.96 0.49~1.47 2.49~1.47 0.09~0.98 0.09~0.98
800℃×3h - - 0.29~1.17 0.29~1.17 0.09~0.98 0.09~0.98
1000℃×3h 0.29~1.17 0.29~1.17 - - - -
Thermal Conductivity(Kcal/m) 250℃ 0.17 0.25 0.16 0.24 0.20 0.17
550℃ 0.20 0.27 0.19 0.28 0.22 0.21
800℃ 0.25 0.31 0.22 0.33 0.27 0.25
1000℃ 0.29 0.35 - - - -
Chemical Composition(%) Al₂O₃ 27 31 30 30 26 25
SiO₂ 53 45 47 49 49 50
Water Required(%) 60 50 67 46 58 62
Setting Type Hydraulic
Installation Method Casting, Gunning
Packaging 25kg
