Monolithic Refractories

SLC Series

SILCA (SLC) is a high-strength, high-density castable. By adjusting the particle size distribution of the fine particles to below a few microns and adding a dispersant and a workability improver, a high-density filler can be obtained with very small amounts of additives. This new type of product also has the following characteristics: it minimizes the use of alumina cement, thereby improving the high-temperature properties.
Item＼Product SLC-18S SLC-18 SLC-17S SLC-17
Maximum Service Temperature(℃) 1800 1800 1700 1700
Dry Material Required for Estimating(t/㎥) 3.00 2.85 2.70 2.60
Permanent Linear Change(%) 110℃×24h -0.03 -0.03 -0.06 -0.06
1000℃×3h -0.12 -0.12 -0.19 -0.16
1500℃×3h +0.20 -0.10 -0.40 -0.42
Cold Crushing Strength(N/㎟) 110℃×24h 49.0~78.4 39.2~68.6 58.8~78.4 49.0~68.6
1000℃×3h 58.8~88.2 49.0~78.4 68.6~88.2 58.8~78.4
1500℃×3h 88.2~117.6 78.4~107.8 88.2~107.8 78.4~98.0
Modulus of rupture strength(N/㎟) 110℃×24h 8.82~12.74 5.88~8.82 8.82~10.78 7.84~9.80
1000℃×3h 12.74~15.69 8.82~11.76 10.78~12.74 9.80~11.76
1500℃×3h 13.72~17.65 9.80~13.72 13.72~15.69 12.74~14.70
Thermal Conductivity(Kcal/m) 250℃ 1.34 1.32 1.27 1.24
550℃ 1.42 1.40 1.18 1.12
800℃ 1.53 1.49 1.20 1.16
1000℃ 1.62 1.57 1.27 1.21
Chemical Composition(%) Al₂O₃ 92 88 74 69
SiO₂ - - 19 24
Water Required(%) 5.5 5.7 5.9 6.2
Setting Type Hydraulic
Installation Method Vibration
Packaging 25kg
Item＼Product SLC-16G SLC-16 SLC-15 -
Maximum Service Temperature(℃) 1600 1600 1500 -
Dry Material Required for Estimating(t/㎥) 2.40 2.45 2.25 -
Permanent Linear Change(%) 110℃×24h -0.06 -0.06 -0.06 -
1000℃×3h -0.22 -0.15 -0.18 -
1500℃×3h -0.70 -0.50 - -
Cold Crushing Strength(N/㎟) 110℃×24h 29.4~49.0 39.2~58.8 39.2~58.8 -
1000℃×3h 39.2~58.8 49.0~68.6 49.0~68.6 -
1500℃×3h 68.6~88.2 78.4~98.0 49.0~68.6 -
Modulus of rupture strength(N/㎟) 110℃×24h 7.84~9.80 8.82~11.76 8.82~10.78 -
1000℃×3h 8.82~11.76 9.80~13.72 9.80~12.74 -
1500℃×3h 10.75~12.74 12.74~16.67 - -
Thermal Conductivity(Kcal/m) 250℃ 0.84 0.85 0.76 -
550℃ 0.86 0.88 0.79 -
800℃ 0.90 0.92 0.82 -
1000℃ 0.95 0.98 0.84 -
Chemical Composition(%) Al₂O₃ 56 55 52 -
SiC 38 39 42 -
Water Required(%) - 7.0 7.0 -
Setting Type Hydraulic
Installation Method Vibration
Packaging 25kg
